Description
| Model number | IFS-40-OP | |
| Power type | Liquid Propane |
|
| Total BTU/hr. | 105,000 (31 KW) | |
| Manifold pressure | 5.0 | |
| Installation type | Floor model | |
| Burner style | Open pot, burners on outside of frypot | |
| Burner material | Ceramic plate | |
| Number of burners | N/A | |
| Baffle system | N/A | |
| 100% Safety shut-off valve | Yes | |
| Material | Stainless steel | |
| Oil capacity | 40 Lbs. (22 L) | |
| Frying area | 14" x 14" (356 x 356 mm) | |
| Cool zone | Deep cold zone area | |
| Robotic welding | Yes | |
| Thermostat | Snap acting, 200° F - 400° F (93° C - 204° C) | |
| Crumb screen | Fine mesh | |
| Bottom drain | Recessed, 1-1/4" (32 mm) full port | |
| Number included | 2 | |
| Material | Nickel-plated wire mesh | |
| Dimensions | 6-1/2" x 12-3/4" x 5-1/4" (165 x 324 x 133 mm) | |
| Handle | Vinyl coated | |
| Wrap material | Stainless steel exterior, except back | |
| Basket hanger | Stainless steel | |
| Door | Stainless steel, double panel | |
| Dimensions | 15-1/2" w x 30-1/2" d x 45-3/4" h (394 x 775 x 1162 mm) | |
| Bottom structure | Full structural support | |
| Legs | 6" (152 mm) Stainless steel | |
| Crated dimensions | 18" w x 34" d x 35" h (457 x 864 x 889 mm) | |
| Ship weight | 221 Lbs. (100 Kg) |
Spec Sheet
